Description

Anden A320V3 is designed and built for grow facilities, with materials intended for demanding grow-room conditions. It removes 315 pints per day at 80°F and 60% relative humidity, with an energy factor of 2.6 L/kWh (5.5 pints/kWh).

Onboard and remote monitoring, sensing and diagnostics support humidity control. The self-sealing, accessible filter protects internal components. Included hanging brackets also serve as lifting handles, the pre-installed plug can be removed for field hardwiring, and float-switch terminals simplify setup. The included A77 control communicates diagnostics to its display.

Whether you are starting seedlings, rooting cuttings or drying, humidity control is critical. Humidity rising above 60% can lead to molds, mildews, and other unwanted biological growth. High humidity can also prevent plants from properly taking in CO2, preventing efficient photosynthesis. Anden helps create an environment that drives transpiration at an optimal rate, while helping prevent disease outbreaks.

The five-year warranty covers all parts, including the refrigeration system. P-trap and hanging brackets included; leveling feet are sold separately (5789).

Specifications

• UL registration: Yes
• Barcodes: 686720032035 (UPC-A)
• Shipping Weight: 192 lbs.
• Moisture removal: 315 pints/day at 80°F / 60% RH
• Energy factor: 2.6 L/kWh; 5.5 pints/kWh
• Electrical supply: 277 VAC, single phase, 60 Hz
• Current: 9.2 A
• Power: 2450 W
• Total cooling load: 7,900 BTU/h at 80°F / 60% RH
• Ratings basis: AHAM DH-1 2008, 80°F / 60% RH inlet, 0.0 in. ESP, 277 VAC
• Airflow: 830 CFM
• Power cord: L7-20P, 10 ft; field hardwiring supported
• Recommended breaker: 20 A
• Dimensions: 32⅝ W × 24 H × 24¼ L in
• Weight, manufacturer specification: 180 lb
• Filter: MERV 11, 20 × 22 × 2 in
• Refrigerant: R410A
• Drain connection: ¾-inch FNPT
• Warranty: 5 years, all parts including refrigeration

Data Sheet

• Download the spec sheet: here
• Download the Anden A210 V1 A320 V1 A320 V3 Dehumidifier Quick Start Guide: here
• Download the Anden A320 V1 A320 V3 Dehumidifier Installation Guide: here

Kit Contents

• Dehumidifier
• Filter
• Hanging brackets
• A77 control
• Drain fittings
• 10 ft of ¾-inch-ID drain tubing
• 30 ft of 20-gauge four-conductor thermostat wire
• Screwdriver
• ¾-inch P-trap
